AC/DC Current Clamp-on
GPS-270
AC/DC current clamp-on with True-RMS
Great performance perfect for any AC or DC current measurement situations
This current clamp meter is designed for current measurement in electrical testing, and combines a digital multimeter with a clamping current sensor. The nature of the clamp means that it can fit around a wire at any point to sense AC or DC current. This has the advantage of allowing electricians to take a reading from a conductor without touching it, which is both more convenient and safer than other methods.
The top-of-the-line True-RMS clamp meter, large jaw measures AC/DC current and voltage, ohms, display hold, motor start-up current (in-rush), frequency, MIN/MAX capability and a large backlit display.
| Model | GPS-270 |
| Current AC accuracy | 400.0A, 800A 1.5% ± 5d |
| Current DC accuracy | 400.0A, 1000A 2% ± 5d |
| Voltage AC accuracy | 400mV/4.000V/40.00V/400.0V/600V 1% ± 4d |
| Voltage DC accuracy | 400mV/4.000V/40.00V/400.0V/600V 0.5% ± 3d |
| Ohms accuracy | 400.0Ω to 40.00MΩ 1% ± 4d |
| Capacitance accuracy | 50.0nF to 3000µF 3.5% ± 6d |
| Max conductor | 50mmØ |
- DC1000A/AC800A Clamp-on + full multimeter ranges
- 50mm large jaw opening
- Fully auto-ranging on all functions for ease of use
- 4000 counts high resolution; fast measurements
- 600VAC/DC input protection on all functions
- AC True RMS voltage and current functions
- Back light display
- 30ms Max HOLD to capture in-rush currents
- Data Hold
- Relative zero feature
- DCV 0.1mV to 600V
- ACV 0.1mV to 600V
- DCA 0.1A to 1000A non-invasive current measurements
- ACA 0.1A to 800A non-invasive current measurements
- Ohm 0.1Ω to 40.00 MΩ
- Capacitance 0.01nF to 3000µF
- Fast audible continuity Diode test
- Battery cover with probe holders
- Rugged fire retarded casing; soft carrying pouch
- Transient protection 6.5KV 1.2/SOµs lightning surge
30-Days Protection
Money back guarantee (UK customers only)
24/7 Guarantee
Support guarantee
1-Year Warranty
Available on all products
Ordering Information
Support
Extra information relating to this product
No optional accessories available
Datasheet (628kb)
- These meters are used mainly for measuring high-level current. By using digital multimeters we cannot measure the current of 10A for more than 30secs without damaging the meter.
- The applications of these meters mainly include industrial controls, industrial equipment, commercial, industrial, residential electrical systems & HVAC.
- These are used for repairing accessible systems based on the requirement.
- These are used to troubleshoot fixing problems, execute last circuit tests, and manage beginner electricians while fitting electrical instruments.
- These are used to execute scheduled, preventive protection as well as troubleshooting of the system.
1-year warranty (subject to product registration with GPS LTD).
Visit www.gpslimited.com/register-product
Service and calibration available.
